Field Fence
Anti-rust Farm Fixed Knot Cattle Fence Woven Livestock Deer Mesh Fence Hot Dipped Galvanized Field Grassland Fence
Product Description
Field livestock fences are made from high-strength galvanized steel wire using a fully automated mechanical weaving process. They are primarily used for livestock isolation and ecological protection in grassland pastures, farms, and other areas.
Features
It uses 2.5mm diameter galvanized steel wire and are weaved using a loop-type mechanical weaving process, resulting in a smooth, uniform mesh surface. Anti-corrosion treatments include hot-dip galvanizing (typically 60-100 g/m2), high-zinc coating (230 g for humid regions), or cold-dip galvanizing (for Africa) for enhanced corrosion resistance. A corrugated structure with a 12mm deep and 40mm wide ripple pattern is used between the meshes to enhance impact resistance and cushioning. They prevent livestock from crossing the fence and protect grassland resources. They are also suitable for use around farmland, orchards, and other areas to prevent wildlife from damaging crops.
products specification
| FIELD CATTLE FENCE | |||
| Mesh sizes | G.W.(KG) | Wire diameter(mm) | |
| 7/150/813/50 | 102+114+127+140+152+178 | 19.3 | 2.0/2.5mm |
| 8/150/813/50 | 89(75)+89+102+114+127+140+152 | 20.8 | 2.0/2.5mm |
| 8/150/902/50 | 89+102+114+127+140+152+178 | 21.6 | 2.0/2.5mm |
| 8/150/1016/50 | 102+114+127+140+152+178+203 | 22.6 | 2.0/2.5mm |
| 8/150/1143/50 | 114+127+140+152+178+203+229 | 23.6 | 2.0/2.5mm |
| 9/150/991/50 | 89(75)+89+102+114+127+140+152+178 | 23.9 | 2.0/2.5mm |
| 7/150/1245/50 | 102+114+127+140+152+0178+203+229 | 26 | 2.0/2.5mm |
| 10/150/1194/50 | 89(75)+89+102+114+127+140+152+178+203 | 27.3 | 2.0/2.5mm |
| 10/150/1334/50 | 89+102+114+127+140+152+178+203+229 | 28.4 | 2.0/2.5mm |
| 11/150/1422/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 30.8 | 2.0/2.5mm |
| DEER FENCE | |
| Vertical wire distance | 3", 4", 5", 6", 7" |
| Mesh width | 75mm, 150mm, 300mm, 450mm(3" , 6", 12", 18") |
| Wire diameter | 2.4mm-2.6mm |
| Knot wire | 2.0mm-2.24mm |
| Roll width | Any length ≤2.5m |
| Roll length | 50m, 100m ,200m |
Field Fence Advantage
Small openings on the bottom to keep small wild animals out
Wide openings on the top to keep large wild animals away and livestock confined
Resistant to animal impacts
Extremely weather resistant
Easy to install and Long lasting
Fixed-knot, Extra and uniformly zinc coated
Ranch Fence Knot
Hinge Joint Knot
The hinge joint knot is composed of multiple, vertical wires that are wrapped around each horizontal wire. It makes a stronger fence than barbed wire, It's where the up-and-down wires gently hold onto the side-to-side wires at each crossing point. This kind of knot is really good at stopping accidents without hurting horses.this kind of knot is really good at stopping accidents without hurting horses.
Fixed Knot
This knot uses an extra wire to tie the up-and-down wires with the side-to-side wires, making the fence even stronger. It's stronger than the square knot, which helps to keep animals from bumping into the fence and also holds up well against heavy snow. It's a really tough knot that keeps your animals safe and the fence strong.
