Welded Gabion Wall Box Iron Wire Mesh for Gabion Retaining Wall or Nature Fencing with Mounting Connections Protective Gabion
products specification
| Gabion Size (m) | Mesh Opening(mm) | Wire Diameter(mm) | Surface Treatment | Tensile strength | Hot dip galvanized |
| 0.5x0.5x0.5 | Square mesh: | 3.0-6.0 mm | Hot dip galvanized Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum) PVC coated | 300-550Mpa | 40-60g/m2 220-300g/m2 (heavy galvanized) |
| 50x50 | |||||
| 70x70 | |||||
| 1x1×0.3 | 100x100 | ||||
| 1x0.8x0.3 | 150x150 | ||||
| 1x1x0.5 | Rectangle mesh: | ||||
| 1x1x1 | 30X50 | ||||
| 2x1x0.3 | 30X80 | ||||
| 2x1x0.5 | 50X80 | ||||
| 2x1x1 | 50X100 | ||||
| 3x1x1 | 50X150 | ||||
| 4x1x1 | 100X200 | ||||
| All sizes can customized according to your request. | |||||
products description
Welded gabion baskets are popular in architectural applications and are an excellent choice for both residential and commercial landscape designs. As a professional gabion supplier, Gabion Supply understands the need for solutions that fit any project requirement.
If you are looking for a beautiful and functional landscape design, gabion walls offer a versatile solution. They can be used as decorative site walls, seating walls, accent walls, and more. Over the past few years, gabion landscaping structures have gained popularity for their durability and aesthetic appeal.
Gabion baskets can be filled with rocks, glass, or other materials and stacked to form gravity-type walls. Their sturdy design allows you to create contemporary features using natural stone, glass rocks, or logs — resulting in eye-catching installations that are sure to impress.
Gabion walls are highly versatile, making them ideal for a wide range of architectural projects. The mesh can be specified as Galfan-coated or Galfan-coated with an additional organic polymer (PVC) coating, depending on the design requirements.
Gabion Baskets Application
Water conservancy and ecological project construction, garden landscaping
Rockfall prevention
Soil and water conservation
Bridge protection
Soil reinforcement and stabilization
Coastal and seaside protection engineering
