3D Fence Panels
PVC Coated Welded Mesh Fence
Product description
3D Bend Fence is made from high-grade Q235 low-carbon cold-drawn steel wire, cold-drawn low-carbon steel wire, and low-carbon steel wire. It undergoes various anti-corrosion treatments, including electrogalvanizing, hot-dip galvanizing, plastic spraying, plastic dipping, and stainless steel wire (plastic dipping is generally used). It is woven, welded, and bent, often connected with peach-shaped posts, also known as peach-shaped post fence.
Excellent Performance: Made from high-quality raw materials and undergoing special surface treatment, it offers exceptional corrosion resistance. The finished product comes with a ten-year quality guarantee.
Easy Installation: No special accessories are required for installation. The push-on installation method is easy to hold, quick, and cost-effective.
Surface treatment of triangular bend guardrail: galvanized steel strip and steel wire with high adhesion electrostatic polyester spraying. Nearly two hundred colors and frosted surface treatment are available. Fence installation method: (optional) Directly buried installation on low wall or concrete floor. Safety accessories installed through flange (optional). According to the safety protection requirements of the site, elbows, barbed wire and tiger thorns can be added to the fence.
Specifications
Wire diameter: 5.0mm; Mesh size: 50mm x 200mm; Post size: 60mm x 60mm x 2700mm; Mesh Panel size: 2m x 2.5m; Four-row reinforcement ribs; Mesh size: 50x50mm. Customization is possible upon request. Construction: High-strength cold-drawn wire is welded with low-carbon steel wire, then hydroformed and secured to the steel pipe support with connecting attachments. Features: High strength, good rigidity, attractive appearance, wide field of view, easy installation, and a bright and relaxing feel.
| Welded Security Fence(3D) | |||||
| Mesh Dimension(mm) | Wire Diameter(mm) | Fence Height(mm) | Curve Quantity | Fence Width | Post |
| 50*100 | 4mm/5mm | 2000mm | 1-1.3M 2 curves | 2000mm-3000mm | Size OD: 60*60mm or 60×80mm Thickness: 1.2mm or 1.5mm Length: 2.2m or 2.5m |
| 50*150 | 4mm/5mm | 2000mm | 1.6-1.9M 3 curves | 2000mm-3000mm | |
| 50*200 | 4mm/5mm | 2000mm | 1.9-2.1 3 curves | 2000mm-3000mm | |
| 50*200 | 4mm/5mm | 2000mm | 2.1-2.4 4 curves | 2000mm-3000mm | |
| 75x150mm | 4mm/5mm | 2000mm | 1.9-2.1 3 curves | 2000mm-3000mm | |
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coated | |||||
| Color available: RAL 6005 green, RAL 7016 gray, RAL 9005 black,All RAL color customized | |||||
| Note:The fence can be customized according to your required if above specification is not satisfied with you. | |||||
Advantages
Appropriate bending creates a unique aesthetic effect for this product, and the surface is treated with plastic dipping in a variety of colors, such as yellow, green, and red. The combination of different colors of posts and mesh is even more pleasing to the eye. At the same time, this product mostly uses columns with chassis, and installation only requires installing expansion bolts, which is very quick.
Fence Application
railway enclosed network
living area fence
site fence
development zone isolation network
products Features
• High level of rigidity and high anti-corrosion, anti-aging, weather-proof. All series of fences produced conform to the CE standard certification of the Italian inspection agency.
• We can offer Welded Wire Mesh Panel Fence free Design Drawing, supply samples for FREE, Efficient and fast installation and quick to transport. Just inserting hanger design make the post and panels a perfect fixed unit. No extra parts are needed, it is connected with buttons pushing installation, easy and convenient.
• The whole set 3D security fence consists of high-quality panels available in various heights and high-strength steel posts. Fence panel will be fixed to the post by suitable clips and screws according to various post type.
• Long service life more than 30 Years,super durable powder coated security fence assures a long service life for this fence system. This coating is applied for hot dipped galvanization to ensure total protection of panels and posts.
Surface Treatment
Hot dipped galvanized welded mesh + powder coating & PVC coated
Q&A
1. Is your fence sample free?
Yes, we can provide free sample to customer for checking its quality.
2. How many days will the sample fence be finished?
Normally our fence samples will be sent immediately by express in 2~3 days if the goods are in stock.
3. How long does it take you to get fence mass production?
Normally within 20-25 days according to your specific orders quantities.
4. Are you a manufacture?
As multi-speciality factory, We are a leading professional wire mesh specializing wire mesh fence which is verified by well-known testing institutions INTERTEK and alibaba. We currently offer chain link fence, gabion(Welded Gabion/Hexagonal Gabion, wall spike, temporary fence, barbed wires, razor wires1000+ metal wire mesh products, product customization according to customer requirements such as wire diameter openings and other specification, we have reliable shipping agent and provide you reasonable arrangement for delivery, moreover our professional installation team will provide you safe and easy installation assistance to make sure your construction plan complete as scheduled.
5. Is customization available?
Yes, we can OEM according to your detailed request, and we can supply fence drawings as your design. with high strength and good aesthetic effect, we will offer you the best fencing solution.
6. Does your wire mesh products have quality assurance?
Our factory has passed the ISO 9001:2000 quality control, and all series of fences produced conform to the CE standard certification of the Italian inspection agency.
